ARC-200DL Industrial ARC Welding Machine Wide Voltage 145V-560V
The Weldtronix ARC-200DL is a versatile multi-voltage industrial ARC (Stick) and Lift-TIG welder designed to operate continuously across an ultra-wide voltage span of 145V to 560V on single-phase or two-phase power. Featuring adaptive arc force, hot start, VRD (voltage reduction device) for safety, and heavy-duty thermal overload protection, making it the ideal solution for rural worksites, variable generator supply, and demanding field fabrication.
₹16,284
Key Engineering Parameters
20A - 200A
145V - 560V Single / Dual Phase (50/60 Hz)
60% @ 200A
Advanced IGBT Inverter
1.6mm - 5.0mm Compatible
IP21S Industrial Enclosure
Live Showroom Demo & Immediate Pickup
Peenya Industrial Area, Bengaluru · Mon–Sat: 9:00 AM – 8:00 PM
Engineering Datasheet & Applications
| Technology | Advanced IGBT Inverter |
|---|---|
| Input Voltage | 145V - 560V Single / Dual Phase (50/60 Hz) |
| Output Current Range | 20A - 200A |
| Duty Cycle | 60% @ 200A |
| Processes | Stick (MMA) and TIG (Lift TIG) |
| Safety Features | VRD, Thermal Overload, Low/High Voltage Protection |
| Weight | 12 kg |
| Warranty | 2 Years |
